Tesla Model 3 Exploded Supplier Infographic

{"type":"automotive exploded-view supplier infographic poster","topic":"Tesla Model 3 vertical exploded diagram from top to bottom","language":"Chinese","style":"clean professional industrial infographic, white background, high-end corporate presentation, precise 3D product rendering, soft studio shadows, minimal layout, sharp typography","title":{"main":"{argument name=\"headline text\" default=\"Tesla Model 3 纵向分解图（从上到下）\"}","subtitle":"主要部件及供应商（截至 2024）"},"subject":{"vehicle":"{argument name=\"vehicle model\" default=\"Tesla Model 3\"}","view":"front three-quarter view","composition":"vertically stacked exploded assembly with components floating in alignment from top to bottom"},"layout":{"left_panel":{"position":"left two-thirds","count":9,"items":[{"index":1,"label":"车身外覆盖件","note":"铝制","visual":"painted white outer body shell with doors, hood, trunk, lights, no wheels"},{"index":2,"label":"内饰总成","note":"座椅、仪表台等","visual":"interior cabin assembly with four black seats, dashboard, steering wheel, center console mounted on partial chassis"},{"index":3,"label":"车身框架结构","note":"铝制","visual":"bare silver body-in-white structural frame"},{"index":4,"label":"底板总成","note":"含热管理板","visual":"flat metallic underfloor plate"},{"index":5,"label":"电池系统","note":"电芯 + 模组 + 电池包","visual":"large rectangular battery pack with visible module layout and orange high-voltage connectors"},{"index":6,"label":"驱动电机","note":"后置单电机","visual":"single rear drive motor unit floating alone"},{"index":7,"label":"悬架系统","note":"前后悬架","visual":"front and rear suspension subframe assembly with brakes and springs"},{"index":8,"label":"电子电气架构","note":"线束、控制器等","visual":"electronic module assembly with orange cables, controllers, wiring and junction boxes"},{"index":9,"label":"底盘总成","note":"含制动、转向","visual":"rolling skateboard chassis with wheels, battery floor, steering and brake systems"}]},"right_panel":{"position":"right one-third","type":"supplier table","columns":["部件","主要供应商","地区"],"count":9,"rows":[{"part":"车身外覆盖件","supplier":"Novelis","region":"美国"},{"part":"内饰总成","supplier":"延锋国际","region":"中国"},{"part":"车身框架结构","supplier":"华域汽车 / HASCO","region":"中国"},{"part":"底板总成","supplier":"旭升集团 / XUSHENG","region":"中国"},{"part":"电池系统","supplier":"LG Energy Solution","region":"韩国 / 中国"},{"part":"驱动电机","supplier":"Tesla 自研","region":"美国"},{"part":"悬架系统","supplier":"拓普集团 / TUOPU","region":"中国"},{"part":"电子电气架构","supplier":"安波福 / APTIV","region":"爱尔兰 / 中国"},{"part":"底盘总成","supplier":"博世 / BOSCH","region":"德国"}]},"connectors":"dotted leader lines from each numbered left-side label to corresponding exploded component","footer":{"note":"注：供应商信息来源于公开资料整理，实际供应商可能因版本和时间有所变化。","legend_count":3,"legend":[{"label":"美国供应商","color":"green"},{"label":"中国供应商","color":"blue"},{"label":"其他国家","color":"gray"}]}} ,"rendering":{"materials":"painted white body, brushed aluminum structures, black leather seats, dark rubber tires, metallic mechanical parts, orange high-voltage cables","lighting":"neutral studio lighting from upper front, gentle ambient occlusion, soft drop shadows beneath each floating layer","camera":"slightly elevated frontal perspective, centered vertical stack","background":"pure white or very light gray"},"constraints":["preserve all 9 layers in exact top-to-bottom order","show supplier logos or brand-styled text in the table","use Chinese labels throughout the infographic","maintain clean spacing and professional information design","make the 3D components realistic and technically plausible"]}
